| Additional Details |
Tran-Dapt motor mount available. 53-64 F100 use part# 4685. 65-79 F100 use part# 9720., Tran-Dapt motor mount available. 53-64 F100 use part# 4685. 65-79 F100 use part# 9720., Tran-Dapt motor mount available. 53-64 F100 use part# 4685. 65-79 F100 use part# 9720. |
| Application |
Automotive |
| ASIN |
B00J9KN040 |
| Bolts/Studs Included |
Yes, Yes, Yes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Catalytic Converter(s) Included |
No, No, No |
| Coating/Finish |
Painted |
| Collector Attachment |
3", 3 in., 3 in. |
| Collector Bolts Included |
Yes, Yes, Yes |
| Collector Diameter |
3 in., 3 in. |
| Collector Size |
3", 3 in., 3 in. |
| Collector Style |
Ball and Socket Style (Gasketless), BALL and SOCKET Style (Gasketless), BALL and SOCKET Style (Gasketless) |
| Collector Tube Size (in.) |
3 |
| Contents |
headers, gaskets (when applicable), 3-bolt exhaust adapters, hardware, headers, gaskets (when applicable), 3-bolt exhaust adapters, hardware, One pair of headers, head flange gaskets, collector flange gaskets (when applicable), 3-bolt exhaust adapters, mounting hardware |
| Country of Origin (Primary) |
US |
| Crossover Pipe Included |
NO, No, No |
| Cylinder Head |
Stock Profile Heads, Stock Profile Heads, Stock Profile Heads |
| Cylinder Head Port Shape |
Oval, Oval, Oval |
| Drivetrain |
2WD Only!, 2WD Only!, 2WD Only! |
| E.O. # |
No, No |
| Emission Code |
Not in CA |
| Emissions Notes |
NOT LEGAL FOR STREET USE ON '75-LATER MODEL YEARS! Legal for off-road use only., NOT LEGAL FOR STREET USE ON '75-LATER MODEL YEARS! Legal for off-road use only., Not Legal For Street Use on '75-Later Model Years! Legal for off-road use only. |
| Engine |
Ford BB 429-460 (385 Series), Ford BB 429-460 (385 Series), 429-460 (385 Series) |
| Engine Make/Size |
Ford 429-460 |
| Engine Notes |
429-460 (385 Series), 429-460 (385 Series), 429-460 (385 Series) |
| Exhaust System Dia |
2-1/2 in., 3", 2-1/2 in. |
| Finish |
Uncoated, Uncoated |
| Finish Type |
Uncoated Mild steel, Uncoated Mild steel, UNCOATED Mild Steel! Shipped with Temporary Paint. |
| Flange Style |
Standard, Standard, Standard |
| Flange Thickness |
0.375", 0.375 in., 0.375 in. |
| Gasket # |
18053 |
| Gasket Or Seal Included |
Yes, Yes, Yes |
| Harmonized Tariff Code (Schedule B) |
8708925000 |
| Hazardous Material Code |
N |
| Head Flange Gasket |
27770 |
| Header Construction |
Standard-Duty, MILD STEEL- Standard-Duty |
| Header Fasteners Included |
Yes, Yes |
| Header Finish |
Uncoated, Uncoated, Uncoated |
| Header Material |
Mild Steel, Mild Steel, Mild Steel |
| Header Port Shape |
Oval Port, Oval Port, Oval Port |
| Header Style |
Short Tube, Short Tube |
| Installation Hardware Included |
Yes, Yes, Yes |
| Life Cycle Status Code |
Available to Order |
| Material |
Stainless Steel, Mild Steel, Mild Steel |
| Motor Mounts (Included) |
NO, No |
| Motor Mounts Included |
NO, No, No |
| Mounting Hardware Included |
Yes, Yes, Yes |
| NAFTA Preference Criterion Code |
B |
| Notes |
54-72 F100 429-460, 54-72 F100 429-460, 54-72 F100 429-460 |
| O2 Provision |
No, No, No |
| Package Contents |
One pair of headers, head flange gaskets, collector flange gaskets (when applicable), 3-bolt exhaust adapters, mounting hardware, Headers, ball and socket reducers (exhaust adapters), gaskets, mounting hardware, Headers, ball and socket reducers (exhaust adapters), gaskets, mounting hardware |
| Port Shape |
Oval, Oval, Oval |
| Primary Tube Diameter (in) |
1.75", 1.75 in., 1.75 in. |
| Primary Tube Gauge |
14g, 14g, 14g |
| Quantity |
Sold as a pair., Sold as a pair., Sold as a pair. |
| Reducer Outlet Size |
3", 2-1/2 in., 2-1/2 in. |
| Reducers Included |
Yes, Yes, Yes |
| Replacement Gasket |
18053, 18053, 18053 |
| Replacement Head Flange Gasket |
27770, 27770 |
| SDR Required Flag |
N |
| Transmission Mount Included |
NO |
| Transmission Mount/Crossmember (Included) |
No, No |
| Transmission Mount/Crossmember Included |
No |
| Tube Design |
SHORT TUBE, SHORT TUBES, Standard |
| Tube Diameter |
1-3/4 in., 1-3/4" |
| Tube Direction |
Down Swept |
| Tube Length |
Short Tubes, Short Tubes, Short Tubes |
| Tube Material Thickness |
14g, 14g, 14g |
| Tube Size |
1.75, 1-3/4", 1-3/4 in., 1-3/4 in. |
| Tube Style |
Shorty, Shorty |
| Tuned |
NO, No, No |
| Variations |
89236, 89236, 89236 |
| Weld-Up |
No, No, No |
| with A.I.R. |
No |
| with A.I.R. System |
No, No, No |
| with EGR |
No, No, No |
| Y-Pipe Included |
No, No, No |
| GTIN |
00732611892308 |
